EPP

Due to its high load characteristics, chemical resistance and strength, expanded polypropylene foam is widely used in the automotive industry, for technical products and for reusable or multi-trip containers. EPP is also extensively used in packaging applications due to its high temperature resistance and excellent creep characteristics, even at low densities.

EPP - Download

General Features
Technical Specifications
Areas Of Usage
Photo Gallery

MATERIAL	TYPE	COLOUR	Moulded Density (gr/l)	Compressive Strength (kPa) at 10% strain /%10 at 25% strain /%25 at 50% strain /%50 at 75% strain /%75	Compression Set (%) 25% / 23°C / 22h 50% / 23°C / 22h	Creep (at 23°C) (kPa) Of 5% after 28 days	Creep (at 23°C) (kPa) Of 5% after 28 days	Cushioning factor C (-) (at 60% strain )	Dynamic Stress d (kPa) (at 60% strain)	Tensile Strength (kPa)	Elongation at Break (%)	Water Absorption (Vol %) 1 Day 7 Days	Burning Behaviour	Temperature Range Constant (°C )	Thermal Conductivity (W/mK)
EPP KÖPÜK-LB15	Expanded Polypropylene	BLACK	190 220 260	%10 1980 2600 3600 %25 2150 2820 3920 %50 3320 4460 6380 %75 8830 11690 16140	---	---	---	---	---	2250 2430 2610	12 12 11	<1.1 3.0 ---- ----	< 100mm/dak	---	---
EPP KÖPÜK-LB15	Expanded Polypropylene	BLACK	85 95 110	%10 540 635 790 %25 625 730 890 %50 890 1040 1300 %75 2070 2500 3220	---	---	---	---	---	1230 1350 1520	17 16 15	<1.1 3.5 <1.1 3.0 <1.1 3.0	< 100mm/dak	---	---
EPP KÖPÜK-MB11	Expanded Polypropylene	BLACK	25 32 40	%10 102 142 191 %25 131 181 240 %50 194 260 340 %75 470 575 720	95 111 130	25% 10 50% 27	22 35 54	2.3 2.2 2.2	350 440 555	395 440 555	27 25 23	<1.1 3.5 <1.1 3.5 <1.1 3.5	< 100mm/dak	---	0.037 0.038 0.039
EPP KÖPÜK-VB15	Expanded Polypropylene	BLACK	60 70 90	%10 330 410 585 %25 395 485 675 %50 565 685 970 %75 1200 1520 2280	175 197 ---	25% 10 50% 27	122 168 ---	2.2 2.3 ---	910 1120 ---	900 140 1290	19 18 17	<1.1 3.5 <1.1 3.5 <1.1 3.0	---	Min . -40 Max. +130	0.042 0.044 ---
EPP KÖPÜK-VB20	Expanded Polypropylene	BLACK	45 55 70	%10 225 300 410 %25 275 355 495 %50 375 485 670 %75 815 1060 2515	142 165 195	25% 10 50% 27	68 103 168	2.2 2.2 2.3	635 810 1120	695 840 1040	20 20 18	<1.1 3.5 <1.1 3.5 <1.1 3.5	< 100mm/dak	---	0.040 0.041 0.044
EPP KÖPÜK-VB20	Expanded Polypropylene	BLACK	38 45 55	%10 178 225 295 %25 225 275 355 %50 320 395 505 %75 680 820 1060	125 141 164	25% 10 50% 27	49 68 103	2.2 2.2 2.2	525 635 810	590 695 840	23 22 20	---	< 100mm/dak	---	0.039 0.040 0.041
EPP KÖPÜK-VB30	Expanded Polypropylene	BLACK	30 36 48	%10 130 166 245 %25 166 210 300 %50 240 300 425 %75 540 640 890	107 121 148	25% 10 50% 27	31 44 78	2.2 2.2 2.2	415 495 685	470 560 740	25 24 21	<1.1 3.5 <1.1 3.5 <1.1 3.5	< 100mm/dak	---	0.038 0.039 0.040
